CSJ coarse grinder
Product Usage
This machine is suitable for pharmaceutical, chemical, metallurgy, food, construction and other industries. Processing of hard and difficult to smash the material, including plastic, copper, Chinese herbal medicine, rubber, etc. crushed, but also as a micro-grinder, ultra-fine grinding machine before processing the ancillary equipment.
working principle
Material from the hopper into the crushing chamber, the impact of the blade and knife seat, rotary knife and fixed knife while cutting and crushing, due to the role of rotating centrifugal force, the material automatically from the exit.
Technical Parameters
| Model number | CSJ-250 | CSJ-500 |
| Feed size | ≤100 | ≤100 |
| Discharge particles | 0.5-20 | 0.5-20 |
| Spindle speed | 940 | 1000 |
| Power | 4 | 11 |
| Yield | 50-300 | 80-800 |
| Dimensions | 860×650×1020 | 1120×1060×1050 |
